KEY POINTS:
Lumbar facet joints can be a cause of your pain.
Facet pain cannot be conclusively diagnosed by standard examination procedures or pain patterns.
Diagnostic nerve blocks are considered the gold standard for confirmation but they also suffer from limitations.
Pain relief from Facet Denervation (Medial Branch Neurotomy), although often significant, is rarely complete or permanent.
The decision on whether or not to consider Medial Branch Neurotomy should be based on understanding the expected outcomes, risks, and limitations of the procedure, in comparison to your current level of function.
Ablating (destroying) the nerve simply eliminates (or reduces) the ability to transmit pain signals. It DOES NOT identify or address the factors causing the pain or sensitization of structures supplied by that nerve.
Introduction:
In 1963, Hirsh et al first demonstrated the capacity of the facet joint to produce pain by the injection of hypertonic saline into the joint. (1) Mooney and Robertson later delineated their typical lower extremity referral patterns now well known to most clinicians. (2) Subsequent investigators have further confirmed the presence of facet joint nerve fibers capable of pain transmission. (3,4,5)
Less well agreed upon compared to the joint’s capacity for pain production is the frequency with which this occurs and the precision with which it can be accurately diagnosed.
The reported incidence of lumbar facet pain shows wide variation. Most studies note an occurrence between 15-45%, depending on the diagnostic criteria utilized. (6,7,8) Schwartzer et al have even suggested a 4% rate for the facet joint serving as a sole source of pain. (9)
Diagnostic precision for implicating facet pain is compromised in ways similar to that of confirming other potential sources of structural involvement.
Spinal imaging, in general, is of little value in most non-neurogenic back pain syndromes. (10,11)
Pertaining specifically to the facet joints, abnormal imaging changes have been shown to have no relationship to the presence or magnitude of pain experienced. (12,13,14)
Adding to the diagnostic dilemma is that no particular pain pattern, clinical bedside test, or combination of tests, can consistently and reliably distinguish facet-mediated pain from that originating in other structures. (15,16,17)
In 1998, Revel et al demonstrated that patients matching 5/7 clinical criteria exhibited a 75% pain reduction on subsequent anesthetic (diagnostic) blocks. These criteria were; age > 65, pain well relieved by recumbent (laying flat) position, absence of pain with coughing, pain not worsened by forward flexion, pain not worsened when rising from flexion, pain not worsened by hyperextension, pain not worsened by extension combined with rotation. (18) Further studies have shown that matching these criteria provide high specificity but very low sensitivity in identifying those likely to benefit from anesthetic blocks. (19,20)
This means that if you match the above criteria, it becomes more likely that you are suffering from facet joint pain (specificity) but NOT matching the criteria does NOT make it LESS likely that your pain is coming from those joints.
In the absence of predictive clinical or radiologic findings, nerve blocks are considered to be the best way of diagnosing presumed facet-mediated pain. (8,21,22)
However, at present, there is no clear consensus on how a diagnostic block should be performed, or the threshold and duration of pain relief that constitutes a positive response. This is largely due to the lack of a gold standard (something concrete or clear cut) test, to which nerve blocks could be compared. (21)
Controlled diagnostic blocks imply having a patient undergo 2 separate injections, at different times, using anesthetic agents of different durations of action. A positive response occurs when a threshold of pain relief (usually between 50-80%) is experienced and the duration of relief is consistent with the known duration of the anesthetic.
Single diagnostic blocks use only a single injection and anesthetic agent.
There are pros and cons to each approach as will be discussed below.
Falco et al, in what appears to be the most recent review on the accuracy of these procedures found that false positive rates (meaning tests that are positive even though the pain is NOT coming from the facet joints) ranged between 17-66% being more common when single blocks or thresholds of pain relief less than 75% were used. (8) Derby et al confirmed this finding, also noting how using pain relief thresholds above 75% correlates with improved outcomes after medial branch neurotomy (facet ablation). (23)
However, additional research by Derby illustrated that using such highly specific criteria may unnecessarily exclude patients who could potentially benefit from interventional denervation. He found that 20% of patients with less than 50% relief and up to 47% of patients with between 50-69% relief, (each considered to be negative responders to diagnostic blocks) went on to show a greater than 50% improvement in pain after undergoing medial branch ablation. (24)
It is also important to understand that pain relief subsequent to medial branch blocks does not implicate the facet joint with certainty.
The medial branch also provides innervation to the multifidus (muscle), interspinous ligaments, periosteum of the neural arch (bone), and the interspinal muscles. (25,26) Ackerman et al further illustrated how the facet joints can be falsely implicated by demonstrating that anesthetic infiltration of the paraspinals (muscles getting injected due to leakage), without direct anesthesia of the medial branch nerve can lead to similar reductions in axial (midline) low back pain. (27)
Although medial branch neurotomy could benefit you, if you match the criteria outlined above, the relief you would achieve would rarely be complete or permanent. Because of this, it is very important that your expectations are realistic if this is something you are considering.
Here are some of the outcomes reported in the literature.
Dreyfuss et al followed 15 patients showing >80% relief on controlled diagnostic blocks. 13 had relief of >60% at one year, with 9 of these exceeding 90% pain reduction. (28)
Lakemeir et al assessed the 6-month response to medial branch neurotomy in 29 patients after showing a minimum of 50% pain relief to a single diagnostic block. Average pain scale reduced from 6.6 to 4.7. Oswestry Index (questionnaire that measures physical function) reduced from 40.8 to 28. This study also compared facet denervation to intra-articular steroid injection, finding no statistical difference between the two procedures. (29)
The response to radiofrequency rhizotomy, after having successful comparative nerve blocks, in Goldfeld et al’s study of 174 patients showed 119 having good (50%) to excellent (80%) pain relief and 55 showing no improvment. 96% of those with good-excellent responses had relief lasting between 6-24 months with 43% of that group showing sustained benefit for 2 years. (30)
Cohen et al followed 262 patients who had a positive controlled diagnostic block with >50% pain relief. Following medial branch neurotomy, 54% had pain relief >50% lasting at least 6 months. There was no difference in response between those reporting >80% relief on confirmatory blocks as compared to those reporting relief of between 50-80%. (31) A later study of his reinforced this finding, further concluding that the use of more stringent diagnostic criteria (higher pain relief thresholds or double as compared to single blocks) would likely result in withholding a beneficial procedure from a substantial number of patients without a corresponding improvement in success rates. (32)
However, Not all studies have shown favorable results for Medial Branch Neurotomy.
One of the largest double blind randomized trials found no difference in VAS (pain scale rating) scores, physical function, or medication use between active intervention and sham (placebo) groups. (33)
Leclair et al found similar disappointing results after monitoring 70 patients who had experienced relief after a single diagnostic facet injection. At 12 weeks, no difference was seen between an active treatment and sham group. (34) Although this was one of the larger studies on facet denervation, it has been criticized for the lack of an adequate description of what constituted a positive diagnostic block. (35) Similar criticism of reports finding evidence of procedural ineffectiveness have been echoed by Bogduk et al, who stated; “Negative results have been reported only in studies that selected inappropriate patients or used surgically inaccurate techniques.” (36)
As briefly discussed earlier, even when Medial Branch Neurotomy is successful, relief is rarely complete or permanent.
Smuck et al reviewed 16 articles finding that the average duration of >50% pain relief for an initial procedure was 9 months. Repeat Medial Branch Neurotomy carried a success rate between 33-85% with an average duration lasting 11.6 months. (37) These statistics were similar to an earlier study also showing a 10-month average duration of benefit for both initial and repeat procedures. (38)
Complication rates with Medial Branch Neurotomy are considered to be low, minor, and in most cases, transient.
Kormick et al had performed 2 studies involving a total of 741 denervations. These revealed 5 cases of neuritic (nerve-related) pain lasting longer than 2 weeks, 5 cases of muscle soreness lasting less than 2 weeks, one case of prolonged muscle spasm, and no instances of motor deficits, sensory deficits, or infections. (39,40)
Some concern has been raised about the possibility of creating a “Charcot Joint” (a joint that becomes severely destroyed) due to the loss of afferent (sensation) input secondary to medial branch ablation. (41) This would appear plausible as the facet joint (and entire medial branch nerve) is not only capable of nociceptive (pain) signaling but also serves a role in proprioception (perception of position and pressure). (42) The loss of proprioception subsequent to denervation could conceivably lead to impaired motor (bodily awareness and activation of proper muscles) control and loss of stability as these receptors are similar to mechanoreceptors (nerve fibers that give your body spatial awareness) involved in the proprioception of other peripheral joints. (43) Recognizing that isolated case reports do not constitute a clear cause-effect relationship; there have been reported cases of progressive kyphosis (severe forward bending of the spine) developing pursuant to multi-level facet denervation. (44,45)
Interventions other than conventional radiofrequency denervation have also been described.
Lakemeier’s study, mentioned earlier found that 6 months after intra-articular steroids, VAS scale (0-10 pain ratinig) reduced from 7 to 5.4 and Oswestry went from 38.7 to 33 (this indicates just minimal, if any, improvement). This was no different than radiofrequency denervation. (29).
Manchikanti et al, studying 120 patients, found that intra-articular injections of an anesthetic agent, either with or without steroids, provided similar pain relief. Over 85% of the patients experienced > 50% pain relief, and >40% improvement in disability measures, with an average effect duration of 19 weeks. Over 2 years, these patients required, on average, 5-6 treatments to maintain their benefit. (46) At present, no clear consensus exists on the comparative effectiveness of direct facet injections versus medial branch neurotomy and a study is currently underway to assess this. (47)
Conventional radiofrequency treatment has been compared with pulsed radiofrequency in two randomized trials, both of which found superiority with conventional radiofrequency. (48,49)
Kryorhizotomy uses a cold probe as compared to a heating element to accomplish medial branch denervation. 3 low quality trials have been performed reporting that properly selected patients experienced an average of 40-60% pain relief over a one-year period. (50,51,52)
To date, there have been no large case series reports, or comparative studies, to properly assess the effectiveness of laser facet denervation.
Iwatsuki et al, reported that 17/21 patients experienced > 70% pain relief one year after laser intervention. (53) Another study of 15 patients having a positive response to double controlled diagnostic blocks reported 8 with complete relief, and 6 with > 50% relief at one year. (54) These isolated reports should not imply that laser denervation is superior to other procedures but rather that larger case controlled or comparative studies are needed.
In summary, Medial Branch Neurotomy could be considered an option if you are suffering persistent low back pain unresponsive to less invasive conservative measures.
But remember, even though it has not yet bee established conclusively who may, or may not benefit from this treatment, it IS important that YOU meet the criteria that the research has shown to indicate a greater chance of treatment success.
In general, if you get > 50% pain relief on controlled diagnostic blocks (and possibly even a single diagnostic block) you could expect to experience similar relief with medial branch neurotomy for an average duration of 6-12 months. A a repeat medial branch neurotomy would tend to yield similar results.
Immediate complications of medial branch neurotomy are mild and transient. However, studies on long-term complications, in particular those experienced in patients having multi-level or multiple sequential blocks, have not been done. This is a case for concern and warrants further study.
At present, the research favors conventional thermal radiofrequency neurotomy over pulsed radiofrequency procedures. Some articles have suggested that intra-articular facet injections of anesthetic with or without steroids may offer similar benefit. To date, laser denervation lacks the research necessary to make firm conclusions.
Beating Low Back Pain Shouldn’t Be Complicated. Learn About SpineCamp Workshops HERE
REFERENCES
Hirsch C, Ingelmark BE, Miller M. The anatomical basis for low back pain. Studies on the presence of sensory nerve endings in ligamentous, capsular and intervertebral disc structures in the human lumbar spine. Acta Orthop Scand. 1963;33:1-17
Mooney V, Robertson J. The facet syndrome. Clin Orthop Relat Res. Mar-Apr 1976;115:149-56.
Cavanaugh JM, Lu Y, Chen C, Kallakuri S. Pain generation in lumbar and cervical facet joints. J Bone Joint Surg Am 2006;88:63-67
Bogduk N, Wilson AS, Tynan W. The human lumbar dorsal rami. J Anat 1982; 134:383-397
Cavanaugh JM, Ozaktay AC, Yamashita T, Avramov A, Getchell TV, King AI. Mechanisms of low back pain: A neurophysiologic and neuroanatomic study. Clin Orthop Relat Res 1997; 335:166-180
Manchikanti L, Boswell MV, Singh V, et al. Prevalence of facet joint pain in chronic spinal pain of cervical, thoracic, and lumbar regions. BMC Musculoskelet Disord. 2004;5:15.
Manchikanti L, Singh V, Pampati V, et al. Evaluation of the relative contributions of various structures in chronic low back pain. Pain Physician. 2001;4:308-316
Falco FJ1, Manchikanti L, Datta S, Sehgal N, Geffert S, Onyewu O, Singh V, Bryce DA, Benyamin RM, Simopoulos TT, Vallejo R, Gupta S, Ward SP, Hirsch JA. An update of the systematic assessment of the diagnostic accuracy of lumbar facet joint nerve blocks. Pain Physician. 2012 Nov-Dec;15(6)
Schwarzer AC, Aprill C, Derby R, Fortin JD, Kine G, Bogduk N. Clinical features of patients with pain stemming from the lumbar zygapophysial joints. Is the lumbar facet syndrome a clinical entity? Spine. 1994;19:1132–1137.
Bechara BP1, Agarwal V, Boardman J, Perera S, Weiner DK, Vo N, Kang J, Sowa GA. Correlation of pain with objective quantification of magnetic resonance images in older adults with chronic low back pain. Spine 2014 Mar 15;39(6):469-75
Boden SD, et al. Abnormal magnetic resonance scans of the lumbar spine in asymptomatic subjects: a prospective investigation. J Bone Joint Surg (Am), 1990; 72A:403-408.
Makki D, Khazim R, Zaidan AA, Ravi K, Toma T. Single photon emission computerized tomography (SPECT) scan-positive facet joints and other spinal structures in a hospital wide population with spinal pain. Spine J 2010; 10:58-62.
Simon P, Espinoza Or.as AA, Andersson GB, An HS, Inoue N. In vivo topographic analysis of lumbar facet joint space width distribution in healthy and symptomatic subjects. Spine (Phila Pa 1976) 2012; 37
Kalichman L, Li L, Kim DH, et al. Facet joint osteoarthritis and low back pain in the community-based population. Spine 2008;33:2560–65
Schwarzer AC, Aprill C, Derby R, Fortin JD, Kine G, Bogduk N. Clinical features of patients with pain stemming from the lumbar zygapophysial joints. Is the lumbar facet syndrome a clinical entity? Spine. 1994;15:1132–1137
Manchikanti L, Pampati V, Fellows B, Baha GA. The inability of the clinical picture to characterize pain from facet joints. Pain Physician. 2000;3:158–166.
M. J. Hancock, C. G. Maher, J. Latimer, M. F. Spindler, J. H. McAuley, M. Laslett, and N. Bogduk Systematic review of tests to identify the disc, SIJ or facet joint as the source of low back pain. Eur Spine J. Oct 2007; 16(10): 1539–1550
Revel M, Poiraudeau S, Auleley GR, Payan C, Denke A, Nguyen M, Chevrot A, Fermanian J. Capacity of the clinical picture to characterize low back pain relieved by facet joint anesthesia. Proposed criteria to identify patients with painful facet joints. Spine. 1998;23:
M. J. Hancock, C. G. Maher, J. Latimer, M. F. Spindler, J. H. McAuley, M. Laslett, and N. Bogduk Systematic review of tests to identify the disc, SIJ or facet joint as the source of low back pain. Eur Spine J. Oct 2007; 16(10): 1539–1550
Mark Laslett, Birgitta Öberg, Charles N Aprill, and Barry McDonald. Zygapophysial joint blocks in chronic low back pain: a test of Revel's model as a screening test BMC Musculoskelet Disord. 2004;5: 43.
Sehgal N, Dunbar EE, Shah RV, Colson J. Systematic review of diagnostic utility of facet (zygapophysial) joint injections in chronic spinal pain: an update. Pain Physician. 2007;10(1):213–228
David S. Binder and Devi E. Nampiaparampil The provocative lumbar facet joint. Curr Rev Musculoskelet Med. Mar 2009; 2(1): 15–24
Derby R, Melnik I, Lee JE, Lee SH. Correlation of lumbar medial branch neurotomy results with diagnostic medial branch block cutoff values to optimize therapeutic outcome. Pain Med. 2012 Dec;13(12)1533-46
Richard Derby, MD, Irina Melnik, MD, Jongwoo Choi, MD2, and Jeong-Eun Lee, PT. Indications for Repeat Diagnostic Medial Branch Nerve Blocks Following a Failed FirstMedial Branch Nerve Block. Pain Physician 2013; 16:479-488
Linqiu Zhou, Carson D. Schneck, Zhenhai Shao. The anatomy of the dorsal ramus and its implications in lower back pain. Neuroscience and Medicine. 2012, 3, 192-201
Bogduk N. Clinical Anatomy of the Lumbar Spine and Sacrum. 3rd ed. Edinburgh: Churchill Livingstone; 1997:127-144
Ackerman WE, Munir MA, Shang JM, Ghaleb A. Are diagnostic lumbar facet injections influenced by pain of muscular origin? Pain Pract. 2004 Dec;4(4) 286-91
Dreyfuss P, Halbrook B, Pauza K, Joshi A, McLarty J, Bogduk N: Efficacy and validity of radiofrequency neurotomy for chronic lumbar zygapophysial joint pain. Spine 2000; 25:1270–7
Stefan Lakemeier, MD, Marcel Lind,† Wolfgang Schultz, MD, Susanne Fuchs-Winkelmann, MD, Nina Timmesfeld, PhD, Christian Foelsch, MD, and Christian D. Peterlein, MD A Comparison of Intraarticular Lumbar Facet Joint Steroid Injections and Lumbar Facet Joint Radiofrequency Denervation in the Treatment of Low Back Pain: A Randomized, Controlled, Double-Blind Trial. www.anesthesia-analgesia.org July 2013 • Volume 117 • Number 1
Gofeld M, Jitendra J, Faclier G. Radiofrequency denervation of the lumbar zygapophysial joints: 10-year prospective clinical audit. Pain Physician 2007;10:291–99
Steven P. Cohen, MD, Milan P. Stojanovic, MDc, Matthew Crooks, MD Peter Kim, MD, CPT Rolf K. Schmidt, MD, LTC Cynthia H. Shields, MD, LTC Scott Croll, MDb, Robert W. Hurley, MD, PhDa Lumbar zygapophysial (facet) joint radiofrequency denervation success as a function of pain relief during diagnostic medial branch blocks: a multicenter analysis. The Spine Journal 8 (2008) 498–504
Cohen SP, Strassels SA, Kurihara C, Griffith SR, Goff B, Guthmiller K, Hoang HT, Morlando B, Nguyen C. Establishing an optimal "cutoff" threshold for diagnostic lumbar facet blocks: a prospective correlational study. Clin J Pain. 2013 May;29(5):382-91
van Wijk RM, Geurts JW, Wynne HJ, Hammink E, Buskens E, Lousberg R, et al. Radiofrequency denervation of lumbar facet joints in the treatment of chronic low back pain: a randomized, double-blind, sham lesion-controlled trial. Clin J Pain. 2005;21(4):335–44.
Leclaire R, Fortin L, Lambert R, Bergeron YM, Rossignol M. Radiofrequency facet joint denervation in the treatment of low back pain: a placebo-controlled clinical trail to assess its efficacy. Spine. 2001;26:1411–7.
David S. Binder Æ Devi E. Nampiaparampil The provocative lumbar facet joint. Curr Rev Musculoskelet Med (2009) 2:15–24
Bogduk N, Dreyfuss P, Govind J. A narrative review of lumbar medial branch neurotomy for the treatment of back pain. Pain Med. 2009 Sep;10(6):1035-45
Matthew Smuck, MD Ralph A. Crisostomo, MD Kavita Trivedi, DO Divya Agrawal, MD. Success of Initial and Repeated Medial Branch Neurotomy for Zygapophysial Joint Pain: A Systematic Review. PM&R. September 2012 Volume 4, Issue 9, Pages 686–692
Rambaransingh B, Stanford G, Burnham R. The effect of repeated zygapophysial joint radiofrequency neurotomy on pain, disability, and improvement duration. Pain Med. 2010;11:1343–7.
Kornick C, Kramarich SS, Lamer TJ, Todd Sitzman B. Complications of lumbar facet radiofrequency denervation. Spine 2004 Jun 15;29(12)
Craig A. Kornick, M.D., S. Scott Kramarich, M.D., B. Todd Sitzman, M.D., M.P.H., Kenneth A. Marshall, M.D., Juan Santiago-Palma, M.D., Tim J. Lamer, M.D. Complication Rate Associated With Facet Joint Radiofrequency Denervation Procedures. Pain Medicine. Volume 2, Issue 2. 2002
William E Morgan, DC Don’t shoot the messenger…of pain. 8-22-14. http://drmorgan.info/blog/don-t-shoot-messenger-pain/
Ianuzzi A, Little JS, Chiu JB, Baitner A, Kawchuk G, Khalsa PS. Human lumbar facet joint capsule strains: I. During physiological motions. Spine J. 2004;4(2)
Pickar JG, McLain RF. Responses of mechanosensitive afferents to manipulation of the lumbar facet in the cat. Spine. 1995;20(22)
Lakshmi Vas, MD, Nishigandha Khandagale,MD, Renuka Pai, MD. Report of an Unusual Complication of Radiofrequency Neurotomy of Medial Branches of Dorsal Rami. Pain Physician: September/October 2014; 17:E651-E662
Joseph K. Lee, MD Progressive Severe Kyphosis as a Complication of Multilevel Cervical Percutaneous Facet Neurotomy: A Case Report. Spine J. 2012;12:e5-e8
Manchikanti L, Singh V, Falco FJ, Cash KA, Pampati V. Evaluation of lumbar facet joint nerve blocks in managing chronic low back pain: a randomized, double-blind, controlled trial with a 2-year follow-up. Int J Med Sci. 2010 May 28;7(3):124-35
Steven P. Cohen, Johns Hopkins University. Medial Branch Blocks vs. Intra-articular Injections: Randomized, Controlled Study. https://clinicaltrials.gov/ct2/show/NCT02002429
Tekin I, Mirzai H, Ok G, et al. A comparison of conventional and pulsed radiofrequency denervation in the treatment of chronic facet joint pain. Clin J Pain. 2007;23:524–9.
Kroll HR, Kim D, Danic MJ, et al. A randomized, double-blind, prospective study comparing the efficacy of continuous versus pulsed radiofrequency in the treatment of lumbar facet syndrome. J Clin Anesth. 2008;20:534–7.
Barlocher CB, Krauss JK, Seiler RW. Kryorhizotomy: an alternative technique for lumbar medial branch rhizotomy in lumbar facet syndrome. J Neurosurg 2003;98(Suppl 1):14S-20S.
Staender M, Maerz U, Tonn JC, Steude U. Computerized tomography-guided kryorhizotomy in 76 patients with lumbar facet joint syndrome. J Neurosurg Spine 2005;3(6):444-9.
Birkenmaier C, Veihelmann A, Trouillier H, et al. Percutaneous cryodenervation of lumbar facet joints: a prospective clinical trial. Int Orthop 2006; Aug 23[e-pub]
Iwatsuki K, Yoshimine T, Awazu K. Alternative denervation using laser irradiation in lumbar facet syndrome. Lasers Surg Med. 2007 Mar;39(3):225-9
Mogalles AA, Dreval' ON, Akatov OV, Kuznetsov AV, Rynkov IP, Plotnikov VM, Minaev VP. Percutaneous laser denervation of the zygapophyseal joints in the pain facet syndrome. Zh Vopr Neirokhir Im N N Burdenko. 2004 Jan-Mar;(1):20-5;
